gang type cnc lathe sc-46p
产品型号:sc-46p
产品特点
●lathe body uses integral cast iron, slanting degree 30 , anti-bending, anti-torsion, high rigidity
●the main spindle adopts high-precision grade p4 tainwan posa spindle, which uses angular contact ball bearings, and the heavy load design combination is front three and back two, which can effectively ensure the rigidity and accuracy.
●higher rigidity of c3 grade hiwin/pmi roller guide rail, ball screw
●support x/y/z/c 4 axis linkage processing, support turning, milling, drilling, boring, reaming, tapping, carving, punching ect., can complete complex part machining at one time, which can improve product accuracy and reduce process.
●the live head use double-motor driven mode, 4 4 4 power head structure, which greatly meet the needs of customer production and processing
产品详情
加工应用:

医疗器械、五金工具、纺织机械、电子通信、航空航天等

结构配置(功能扩展):




技术参数:


model

sc-46p


nc device

fanuc 0itf

lathe rated power

kw

13

spindle

spindle end face type

ansi a2-5


spindle through hole

mm

φ46


spindle power

kw

5.5


spindle rev speed

rpm

max 6000


spindle center to slanting table distance

mm

75

machining range

spindle max swing dia.

mm

φ400


max turning dia.

mm

φ195

rapid feed speed

m/min

 24(x ,z axis)

feed servo motor power

kw

1.8 (x ,z axis)

max travel

x axis

mm

1100


z axis

mm

350

positioning accuracy

x/z axis positioning accuracy

mm

0.005


x/z axis repeat positioning accuracy

mm

0.005


spindle rotary jumpiness accuracy

mm

0.003

spindle ban-type brake

hydraulic brake

lathe body gradient

°

30°

row type turning tool


¨20

row type boring tool


φ25

cutting oil pump power

kw

0.4

cutting oil tank volume

l

105

net weight

kg

3200

dimensions(l×w×h)

mm

2400×1900×2085

installation size:
